H50series LTE WCDMA GSM Industrial 3g wifi router sim cloner

FOB Reference Price:Get Latest Price
$1.00 - $400.00 / Piece | 1 Piece/Pieces (Min. Order)
Supplier Type:
Retailer Original manufacturer Agency odm
Lead Time:
Quantity(Pieces) 1 - 3 >3
Est. Time(days) 3 Negotiable
$200.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Report Suspicious Activity
Quick Details
Model Number:
M2M/IOT, POS, ATM, Kiosk, CCTV, IP Camera
Brand Name:
Place of Origin:
Guangdong, China
black red
Products Status:
Backup, Failover
LAN Ports:
WAN Ports:
Industrial Modular
Supply Ability
Supply Ability:
100000 Piece/Pieces per Year
Packaging & Delivery
Packaging Details
standard package
Picture Example:
Lead Time :
Quantity(Pieces) 1 - 3 >3
Est. Time(days) 3 To be negotiated

H50series LTE WCDMA GSM router wifi industrial iptv




Product Description


H50series router wifi industrial iptv is a kind of cellular terminal device that provides large data transmission function by public LTE/WCDMA network.




It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It supports RS232 (or RS485/RS422), 5xEthernet and WiFi port that can conveniently and transparently connect devices to a cellular network, allowing you to connect to your existing serial, Ethernet and WiFi devices with only basic configuration.


It has been widely used on M2M fields, such as intelligent transportation, smart grid, industrial automation, telemetry, finance, POS, water supply, environment protection, post, weather, and so on.



Eye catching points:

- Remote Data Monitor

- CCTV surveillance


- Remote POS/ATM

- Vending Machine

- Telemetry

- Vehicle Surveillance and Control

- Bus 3G WiFi etc.


Basic informatin

Flash8MB(Extendable to 64MB)
ApplicationIndustrial Application
Transfer Rate10/100/1000Mbps
WiFi StandardIEEE802.11b/G/N
CPUIndustrial 32bits CPU
Rx Sensitivity<-93.3dBm
Tx Power<32dBm
Port Structure


Standard and BandSupport Lte FDD 2600/2100/1800/900/800MHz, 700/170
Operating temperature-30°C~75°C
Extend temperature -40°C~85°C
Operating Humidity  95% ( Unfreezing)
Voltage rageDC5~32V (standard type 12V)
HousingIron, providing IP30 protection




Tipical Topology




 Product Photos






Features and Benefits

1.Design for Industrial Application

2.High-powered industrial cellular module


3.High-powered industrial 32bits CPU

4.Support low-consumption mode, including sleep mode, scheduled online/offline mode, scheduled power-on/power-off mode(optional)

5.Housing: Iron, providing IP30 protection

6.Power range: DC 5~32V

  Stability and Reliability

1.Support hardware and software WDT

2.Support auto recovery mechanism, including online detect, auto redial when offline to make router always online

3.Ethernet port: 1.5KV magnetic isolation protection

4.RS232/RS485/RS422 port: 15KV ESD protection

5.SIM/UIM port: 15KV ESD protection

6.Power port: Reverse-voltage and overvoltage protection

7.Antenna port: Lightning protection(optional)

  Standard and Convenience

1.Support standard RS232(or RS485/RS422), Ethernet and WiFi port that can connect to serial, Ethernet and WiFi devices directly

2.Support standard WAN port and PPPOE protocol that can connect to ADSL directly

3.Support intellectual mode, enter into communication state automatically when powered

4.Provide management software for remote management

5.Support several work modes

6.Convenient configuration and maintenance interface(WEB or CLI)


1.Support multiple WAN access methods, including static IP, DHCP, L2TP, PPTP, PPPOE, 4G. LTE/

2.Support double link backup between LTE/ WCDMA and WAN(PPPOE, ADSL) (optional)

3.Support VPN client(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)

4.Support VPN server(PPTP, L2TP, OPENVPN, IPSEC and GRE)(only for VPN version)

5.Support local and remote firmware upgrade, import and export configure file.

6.Support NTP, RTC embedded.

7.Support mulitiple DDNS provider service.

8.Support VLANs, MAC Address clone, PPPoE

9.WiFi support 802.11b/g/n. Support AP, client, Adhoc, Repeater, Repeater Bridge and WDS(optional) mode.

10.WiFi support WEP, WPA, WPA2 encryption, Support RADIUS authentication and MAC address filter.

11.Support multi online trigger ways, including SMS, ring and data. 12.Support link disconnection when timeout

13.Support APN/VPDN

14.Support DHCP server and client, firewall, NAT, DMZ host, URL block, QoS, ttraff, statistics, real time link speed statistics etc.

15.Full protocol support, such as TCP/IP, UDP, ICMP, SMTP, HTTP, POP3, OICQ, TELNET, FTP, SNMP, SSHD, etc.

16.Schedule Reboot, Schedule Online and Offline, etc.


Packaging & Shipping


 -- Device Body

 -- RJ45 Cable

 -- WIFI Antenna

 -- 3G/4G Antenna

 -- Power Supply



 We have strong cooperation with DHL, EMS, Fedex, ups, TNT... also support Epacket, Post air mail...

Company Information


Our Services

Payment: T/T, L/C, Credit Card, Western Union and Paypal are all available.

Delivery: For samples, we usually delivery the goods within 3 working days. For batch order, we can send out in 12 working days.

Warranty: 1 year, repaired free during the warranty.

Certificate: CE, RoHs, others can be judged base on the quantity.

OEM/ODM: Supported.



Q1. If i have problems of installation or problems of confusions, how could i solve them?

A1. Do not worry, just send us the messages in below contact ways, we will response you within 12 hours in working days.


Q2. Can we get support if we want a special outlook and function addition ?

A2. No problem! Our Technical team will support you develop a new kind and best solution for you !


Q3. Can I use this model with Sim/Uim Card directly?

A. Yes, users can use without external modem. It built-in radio module. Get a data sim/uim to work directly.


Q4. Does this unit support high gain antenna?

A. Yes. It is packed with standard antenna. If needed, users can replace with high gain or dedicated band antenna.


Q5. Is this model unlocked?
A. Yes. This model is unlocked. Can work with carriers all over the world if it meet the band/frequency specification.
